SC-316, Stainless Steel Sample Cooler
Product Details
Model #:
SC-316
Manufacture:
Eddington
Sample coolers by Eddington Industries are a safe method of withdrawing water from boilers, steam lines or tanks containing chemicals. Sample Coolers are also a safe method for cooling the withdrawn liquid for subsequent chemical analysis.
Shell: Type 304 Stainless Steel
End caps: Type 304 Stainless Steel
¼” MNPT adapters: Type 316 Stainless Steel
Coil: Continuous coil of type 316 stainless steel
Max coil pressure: 2500 psi
Max shell pressure: 250 psi
Overall length: 13 5/8” Long
Diameter of shell: 3 ½” Round.
Mounting: 3” zinc plated pipe clamp
Cooling water fittings: Inlet & outlet, 3/8” or 1/2″ FNPT Type 304 S/S
Weight: 13 lbs.
